Volvo ECR50D - Cab

Relay Relay function
RE3508 Working lights second
RE8705 Air conditioner compressor
Fuses
Fuse Ampere Function
FU01 30 A Main supply
FU02 30 A Glow plug
FU03 30 A Main supply key
FU04 20 A Starter motor
FU05 20 A Stop valve (pull)
FU06 10 A Working light front
FU07 10 A Working light rear and boom
FU08 10 A Horn
FU09 10 A Beacon
FU10 10 A Power outlet
FU11 10 A Compressor, air conditioning relay
FU12 20 A VECU Main supply
FU13 3 A Boom swing / X1 joystick, travel speed switch, quick attach
switch
FU14 3 A Cluster supply
FU15 5 A Armrest switch, safety pilot valve, VECU
FU16 10 A Motor controller supply
FU17 3 A Keypad supply
FU18 5 A VCADS, caretrack supply
FU19 5 A Orientation pressure switch
FU20 5 A Travel alarm
FU21 3 A +15/54 key status
FU22 15 A Heater an switch, heater fan motor, AC motor
FU23 5 A Refueling pump / alternator
FU24 10 A Wiper and washer
FU25 5 A Spare socket for power outlet (comm)
FU26 7.5 A Electronic coded valve supply
FU27 10 A Interior light and radio supply
FU28 3 A Preheater check
FU29 10 A Caretrack supply
NOTE!
Use only fuses of specified capacity (Ampere
rating).
Specifications
Electrical system 189
