10 Menu up
11 Escape
12 Menu down
13 Select
14 ECO mode
15 RPM up
16 not assigned
17 RPM user setup 1
18 RPM down
19 RPM user setup 2
20 not assigned
1 Fast travel speed
After switching to fast travel speed the automatic
control of the travelling speed is activated.
The button is alight if the fast travel speed is
activated.
When a certain resistance appears in front of the
tracks or dozer blade, the travelling speed
automatically drops down to low speed. When
the resistance is gone the speed rises up to high
speed again.
A high speed function push button is also located
in the blade lever, see page
48
.
2 Air conditioning (optional equipment)
Press this button to switch the air conditioning
on and off.
The button is alight if the air conditioning is
activated.
Use the regulator 6 (temperature control) to set
up the desired temperature of the air
conditioning.
3 Auto idle (Automatic engine speed control)
With this button the auto idle system can be
activated or deactivated.
The button is alight if the auto idle function is
activated.
If auto idle is activated, the engine speed will be
lowered automatically to idle mode if no controls
in the cabin are operated for a certain time. This
time can be set from 3 to 60 seconds, see page
31
.
When operating a control lever the engine speed
will rise again up to the speed level set by the
keypad.
44
Instrument panels
Instrument panel, right
