10 Maintenance and service
10
}}
333
2. Rotate the thumbwheel on the left-hand
stalk switch to position
Oil level.
> You will then see information displayed
about the engine oil level.
For more information on menu naviga-
tion, see Menu navigation - combined
instrument panel (p. 101).
NOTE
If the right conditions for measuring the oil
level are not met (time after engine shut-
down, the car's inclination, outside tem-
perature, etc.) then the message
Not
available will be shown. This does not
mean that there is something wrong in the
car's systems.
Engine with electronic oil level sensor,
5-cyl. diesel
Filler pipe.
7
You do not need to take action with respect
to the engine oil level before a message is
shown in the display, see the illustration
below.
Message and graph in the display. The left-hand
display shows the digital combined instrument
panel and the right-hand the analogue.
Message
Engine oil level
The oil level is checked using the electronic
oil level gauge with the thumbwheel when the
engine is switched off, see Menu navigation -
combined instrument panel (p. 101).
WARNING
If the message Oil service required is
shown, visit a workshop. The oil level may
be too high.
7
Engines with electronic oil level sensor do not have a dipstick.
