05 Loading and storage
05
* Option/accessory, for more information, see Introduction.
151
Position the handle in fitting position, see
illustration. Press gently on the handle to
enable it to be turned into position, see
arrow.
Press the strut in towards the grille and
align the grille in the roof mounting.
Turn the handle 90° . Press gently as in
the illustration (1) if necessary. Secure the
grille by angling the handle 90°
.
•
Removal of the grille takes place in
reverse order.
Related information
•
Safety net* (p. 148)
•
Loading (p. 144)
Cargo cover
Pull the cargo cover over the load and hook it
into the recesses at the cargo area's rear
posts.
IMPORTANT
The protective grille cannot be folded up
or down when the cargo cover is fitted.
Attaching the cargo cover
Move one end piece of the cover into the
recess on the side panel.
Move the other end piece into the corres-
ponding recess.
Press both sides in. A "click" should be
audible and the red marking should dis-
appear.
> Check that both end pieces are
locked.
