10 Maintenance and service
10
356
Function A
Solenoid clutch A/C (5, 6-cyl.);
Valves (1.6 l, engine B4204T7;
5-cyl., 6-cyl.); Engine control
module (6-cyl.); Solenoids (6-
cyl. without turbo); Actuator
motors, intake manifold (6-cyl.
without turbo); Mass air flow
sensor (engine B4204T7; 5-cyl.
petrol); Oil level sensor (5-cyl.
diesel)
10
Valves (4-cyl. 2.0 l
B
); Oil pump
(4-cyl. 2.0 l petrol
B
); Lambda-
sond, centre (4-cyl. 2.0 l pet-
rol
B
); Lambda-sond, rear (4-cyl.
2.0 l diesel)
15
Lambda-sonds (1.6 l petrol,
engine B4204T7); Lambda-
sond (5-cyl. diesel); Control
module, radiator roller cover
(1.6 l diesel, 5-cyl. diesel)
10
Lambda-sond, front (4-cyl.
2.0 l
B
); Lambda-sond, rear (4-
cyl. 2.0 l petrol
B
); EVAP valve
(5, 6-cyl. petrol); Lambda-
sonds (5, 6-cyl. petrol)
15
Function A
Coolant pump (1.6 l petrol
Start/Stop); Crankcase ventila-
tion heater (5-cyl. petrol); Oil
pump automatic gearbox(5-cyl.
petrol Start/Stop)
10
Ignition coils (4-cyl. 2.0 l pet-
rol
B
)
15
Diesel filter heater 20
Control module, radiator roller
cover (5-cyl. petrol)
5
Crankcase ventilation heater
(5-cyl. diesel); Oil pump auto-
matic gearbox (5-cyl. diesel
Start/Stop)
10
Solenoid clutch A/C (4-cyl.
2.0 l
B
); Glow control module (4-
cyl. 2.0 l diesel); Oil pump (4-
cyl. 2.0 l diesel)
15
Coolant pump (4-cyl. 2.0 l pet-
rol
B
)
50
Glow plugs (diesel) 70
Function A
Cooling fan (1.6 l, 4-cyl. 2.0 l
petrol, 5-cyl. petrol)
60
Cooling fan (6-cyl., 4-cyl. 2.0 l
diesel, 5-cyl. diesel)
80
Power steering 100
A
For cars with the Start/Stop function this fuse location is
empty - see instead Fuses - in the engine compartment's
cold zone (p. 362).
B
Does not apply to the B4204T7 engine.
C
However, does apply to the B4204T7 engine.
Related information
•
Fuses - under glovebox (p. 357)
•
Fuses - in the control module under the
glovebox (p. 359)
•
Fuses - in cargo area (p. 361)
