03 Instruments and controls
03
}}
89
3. Start from the design line on the head-
lamp lenses; see the dotted line in the fol-
lowing figure. Position the self-adhesive
templates at the right distance from each
design line using the illustration and the
dimensions in the following list:
•
A = LHD Right - approx. 86 mm
•
B = LHD Left - approx. 40 mm
•
C = RHD Right - 0 mm
•
D = RHD Left - approx. 96 mm
