90 Instruments and Controls
A bulb change tool is included with the
ignition keys on the keychain, or can be or-
dered from your Volvo Truck dealer under
part number 1089953. Use only this tool to
change bulbs in the instrument cluster.
To remove bulb, insert tool onto the bulb
assembly, rotate a 1/4 turn counterclock-
wise and pull the bulb assembly out of the
cluster.
Insert a new bulb into the tool and install it
into the cluster. Rotate the bulb a 1/4 turn
clockwise and pull the tool off of the bulb
assembly.
NOTE! The telltale area in the right part of
the instrument does not use all spaces for
active telltales. These bulbs can be used for
spare bulbs.
Lift up the instrument cluster and fasten the
two screws at the top of the cluster.
W3000642
