Lamp replacement - rear lamp
Rear direction indicators are replaced from
inside the cargo area.
Lamp housing, rear
G017456
The direction indictor bulb in the rear lamp
cluster is replaced from inside the cargo area.
1. Open the panel.
2. Remove the insulation by pulling it
straight out.
3. Loosen the bulb holder by turning its han-
dle anticlockwise.
4. Detach the bulb by pulling it straight out.
Related information
•
Lamp replacement - location of rear
lamps (p. 373)
•
Lamps - specifications (p. 375)
Lamp replacement - location of rear
lamps
The overview shows the location of the lamps
at the rear.
Position/parking lights (LED)
Brake light (LED)
Indicator (p. 373)
Side marker lamps (LED)
Reversing lamp (p. 373)
Fog lamp (p. 373)
Brake light (LED)
Related information
•
Lamp replacement - general (p. 369)
•
Lamps - specifications (p. 375)
Lamp replacement - number plate
lighting
The number plate lighting is located under the
tailgate handle.
G017458
1. Remove the screws with a screwdriver.
2. Carefully detach the whole lamp housing
and withdraw it.
3. Replace the bulb.
4. Refit the whole lamp housing and screw it
into place.
Related information
•
Lamps - specifications (p. 375)
