Voodoo Lab Pedal Power 2 Plus User Manual

Specifications
Input: IEC connector
120V 50/60Hz (North America model)
100V 60Hz (Japan model)
230V 50/60Hz (Europe/Australia model)
Model and input power are marked on the bottom of unit.
Outputs: 5.5x2.1mm barrel connectors center negative
Short circuit protected.
Physical: 6” wide x 3.4” deep x 1.75” tall (152x86x45mm)
Weight 2 lbs. (0.9 kg).
Special: Toroidal power transformer.
Auxiliary AC outlet, 200 watts max.
DIP Switch: NORMAL
Output DC Voltage Max current
1- 4 (ACA) 9V 100mA
5-6 (L6) 9V 250mA
7-8 (SAG) 9V 100mA
DIP Switch: ON
Output DC Voltage Max current
1-4 (ACA) 12.3V 60mA
5-6 (L6) 14.5V / 12V (unregulated) 50mA / 200mA+
7-8 (SAG) Adjustable 4V - 9V 100mA

Voodoo Lab Pedal Power 2 Plus Specifications

General

Output Voltage Options	9V, 12V, 18V
Current Capacity	100mA, 250mA
Topology	Isolated outputs
Weight	2 lbs
Input Voltage	120V
Cables Included	Yes
Outputs	8
Dimensions	6 x 3.4 x 1.75 inches (152.4 x 86.4 x 44.5 mm)
