Line6 Tone Core pedals can be powered from any output with its
switch in the “NORMAL” position.
SAG Outputs
Outputs 7 and 8 permit you to adjust or SAG the voltage from about
4V to 9V. To enable this feature you must set the corresponding
switch to the “ON” position. This allows you to simulate worn bat-
teries. This is mostly useful for transistor-based fuzz and distortion
circuits, as modern opamp designs are minimally affected by vari-
ations in supply voltage. It is not recommended for digital pedals.
More About Cables
The DC power cables supplied with your Voodoo Lab Pedal Power 2
are suitable for most common pedal effects. If you need additional
cables they are available directly from Voodoo Lab. If you need
cables of a different length, with reversed polarity, or with a special
connector, contact us and we can provide them for you.
Visit www.voodoolab.com/cables.htm for more information.
Operation
Using the above information, connect the DC power cables between
the Pedal Power outputs and the power jacks on your pedal effects.
Now connect the AC power cord from the AC Power Input jack on
the Pedal Power to a suitable AC outlet. The Pedal Power’s red LED
power indicator should light telling you that it’s working properly.
