VOODOO LAB PEDAL POWER
User’s Manual
Introduction
The Voodoo Lab Pedal Power is the finest power supply available
for pedal effects. The Pedal Power provides eight 9V outputs which
will power any type of battery operated effects. Each output is com-
pletely isolated, short-circuit protected, highly filtered and regulated.
This insures reliable operation, free of hum and noise.
The new Pedal Power 2 Plus now powers Line6 modeling pedals,
Boss Twin pedals, and includes two variable voltage outputs to
simulate worn batteries. The U.S. model (120V input) can operate
from 50Hz or 60Hz mains to allow use with a step-down trans-
former in 50Hz countries.
Please take the time to read this entire manual before operating
your Voodoo Lab Pedal Power. This will eliminate the possibility
of damage to your effects from improper usage. You can also visit
our web site at www.voodoolab.com for the latest information on
this and other products.
Unpacking
Your Voodoo Lab Pedal Power box should contain the following:
Pedal Power 2 Plus system unit
Warranty card
AC power cord
DC Power cables:
5.5x2.1mm barrel connectors (6)
5.5x2.5mm “red” barrel (2)
3.5mm mini plug (1)
9V battery snap (1)

Voodoo Lab Pedal Power 2 Plus Specifications

General

Output Voltage Options	9V, 12V, 18V
Current Capacity	100mA, 250mA
Topology	Isolated outputs
Weight	2 lbs
Input Voltage	120V
Cables Included	Yes
Outputs	8
Dimensions	6 x 3.4 x 1.75 inches (152.4 x 86.4 x 44.5 mm)
