10
2) Press buttons #1 through #4 to select the number group:
CC Group LED #4 LED #3 LED #2 LED #1
80-87 OFF OFF OFF ON
88-95 OFF OFF ON OFF
64-71 OFF ON OFF OFF
56-63 ON OFF OFF OFF
3) Remove power when finished.
Factory Reset
You can restore the factory default settings and clear any saved presets.
1) Apply power while holding down both buttons #2 and #3. The LEDs will flash until
you release the buttons.
2) LED #1 will be on. Press button #1.
3) Press buttons #2 through #8 as each LED comes on.
4) The LEDs blink three times and then stay off when finished. Remove power.
