3. DESCRIPTION OF THE UNIT
1 Cover of the chamber
2 Ceramic table
3 Lift table
4 Cooling pad
5 Front panel
7 Mains switch
8 Mains fuses - 8А/250V
9 Plug of power cord
10 Plug of pump’s power cord
11 Fuse for vacuum pump - 1,25А/250V
12 Nozzle of pump’s hose
13 Hose of the vacuum pump
14 Adapter
15 Vacuum pump
1
2
3
4
5
10
11
12
9
8
7
14
15
16
