DESCRIPTION OF INDICATION
This furnace has 2 LINE LCD display.
The LINE 1 shows following information:
Sector”№ PROGRAM” shows the number of the chosen
program for execution or the program for entering of
parameters;
Sector "H:MM:SS" - shows the time remaining to the end
of the executed program.
Sector"V %" - shows the depth of the vacuum in %.
Sector"°C" - Indicates the current temperature in the
chamber.
The LINE 2 shows following information:
Sector "MODE" – displays information of the current stage;
Sector "PROGRAM NAME" – shows the name of the
selected program.
Indicator 1: the furnace is in the phase of drying.
Indicator 2: the furnace is in the phase when the tempera-
ture increases to the value for firing.
Indicator 3: the furnace is in the phase of firing.
Indicator 4: the furnace is in the phase of cooling.
Indicator 5: the vacuum pump is switched on.
