Vornado PIVOT 3U User Manual

11
English
1. Remove the 4 screws located in between the
ribs of the inlet grille at roughly 2, 5, 7, and
10 o’clock positions.
2. Dust or wash Front Grille with a mild
dishwashing soap. Do not place grille in the
dishwasher. The excessive heat can distort
the plastic.
3. To reattach - position the Front Grille so the
Vornado logo in the center of the Front Grille
is straight. Replace all the screws.
CLEANING
GRILLE REMOVAL Screwdriver required.
WARNING: To reduce the risk of electrical shock and injury to persons, unplug the circulator
before removing grille.
Screw
Use the brush attachment on your house-
hold vacuum cleaner to vacuum any
accumulated dust off the Front Grille and
Air Inlets.
Note: The motor is permanently lubricated
and requires no oiling.
Screw
ScrewScrew
