9
English
1. Remove the 3 screws located in between
the ribs of the inlet grille at roughly 2, 5
and 9 o’clock positions. Screw locations
are also indicated with an arrow (
) on
the circulator.
2. Dust or wash Front Grille with a mild
dishwashing soap. Do not place grille in the
dishwasher. The excessive heat can distort
the plastic.
3. To reattach - position the Front Grille so
the Vornado logo in the center of the Front
Grille is straight. Replace all the screws.
CLEANING
GRILLE REMOVAL Screwdriver required.
WARNING: To reduce the risk of electrical shock and injury to persons, unplug the circulator before removing grille.
Screw
Screw
Screw
Use the brush attachment on your household
vacuum cleaner to vacuum any accumulated
dust off the Front Grille and Air Inlets.
Note: The motor is permanently lubricated
and requires no oiling.
