DIAMON DBACK
™
HD 2000
2 3
DIAMONDBACK
™
HD 2000
LASER RANGEFINDER
The Diamondback
™
HD 2000 is an essential companion
for the everyday hunter, archer, and shooter. This angle
compensated rangefinder features two target modes,
Normal and Last, and two range modes, Horizontal
Component Distance (HCD) and Line of Sight (LOS) Mode,
for any ranging environment.
Images are for representation only.
Product may vary slightly from what is shown.
Specifications
MAGNIFICATION 7x
OBJECTIVE LENS 24mm
MAX REFLECTIVE RANGE Up to 2000 yds. (1829m)
TREE RANGE Up to 1800 yds. (1646m)
DEER RANGE Up to 1400 yds. (1189m)
MINIMUM RANGE 5 yds. (4.5m)
ACCURACY
± 1 yd. @ ≤ 100 yds.
± 2 yds. @ ≥ 100 yds. & ≤ 500 yds.
± 3 yds. @ ≥ 500 yds.
MAXIMUM ANGLE READING ± 60°
FIELD OF VIEW
Linear @ 1000 yds. 335'
Angular 6.4°
EYE RELIEF 16mm
BATTERY TYPE CR2
BATTERY LIFE 2000 + Range Cycles at Brightness Level 3
LENGTH 4.1" (103.4mm)
HEIGHT 3.1" (79.5mm)
WIDTH 1.8" (45mm)
WEIGHT W/ BATTERY 7.6 oz. (215.5g)
