Vortex ROK DVS J - Fuel Pump Bracket Option 1

ENGINE ASSEMBLING
DVS-Junior
12
Fuel Pump Bracket Option 1
5 mm. Allen Wrench
Part I
Insert and tighten the silent blocks in the designed
bracket.
Attach the bracket to the engine with 6 mm screws
provided. (Red arrow)
Part II
10mm Fixed Wrench
Insert the fuel pump into the silent blocks and
tighten it.
