Spark Plug Wrench
Remove the plastic cap from the head of the cylinder.
Manually tighten the spark plug into the cylinder
head.
Lock it with the spark plug wrench. Loosen it then
retighten 2/3 consecutive times; so as to allow the spark
plug washer to seat properly. Now you can tighten the
spark plug properly. Insert the high tension lead into the
spark plug cap and tighten it. For safety, we recommend
you secure the high tension lead to the spark plug cap
with a cable tie.
Place the spark plug cap on the spark plug and press
the cap down fully.
10mm Fixed Wrench
5mm Allen Wre
n
c
h
Diagram to assemble fuel pump and bracket option 1. Proceed as explained in
next page. All material needed to perform this task is provided with the engine.
To Next Page
