Insert now the ground cable previously
attached to the crank case in the bottom silent
block as per photo.
Tighten with washer and nut.
Caution: One side of the ground
cables
m
a
y
touch the crank case.
The other ends may touch coil support.
Please check photo to correct coil assembling.
Wrongly ground cables assembling
will result in failure and coil
irreversible damage.
