Vortex ROK DVS J User Manual

PARTS
103 W511/10 Vite TBCE M6x10 Roundhead screw M6x10 10
104 W570/12 Rondella piana 6x12x1.5 ZNB Flat washer 6x12x1.5 ZNB 10
105 W10662 Guarnizione rame 6x10x1,5 Copper gasket 6x10x1,5 10
106 V.TCE6X40 Vite brugola M6x40 Socket-head screw M6x40 10
106A V.TCE6X45 Vite brugola M6x45 Socket-head screw M6x45 10
107 W310 Paraolio FPJ 20x35x7 doppio labbro Oilseal FPJ 20x35x7 doubble lips 1
108 W530/10FL Dado m8 chiave 10 flangiato Nut m8x10 10
109 W10042/1 Prigioniero base cilindro M8x55 Cylinder studbolt M8x55 1
109A W10042/KF Prigioniero base cilindro M8x49 Cylinder studbolt M8x49 1
110 W10552 Paraolio pignone 25x40x7 Sprocket seal 25x40x7 1
111 W075/1 Bussola carter 10x10,5x6,5 Crankcase dowel 10x10,5x6,5 1
112 W015 Raccordo acqua testa/cilindro Water head pipe fitting 1
113 W1766/1ROK Spina cilindrica 6x12 Cylindrical pin 6x12 1
114 W10662 Guarnizione rame 6x10x1,5 Copper gasket 6x10x1,5 10
115 W800/ROK Raccordo presa depressione Depression pipe fitting 1
118 W512/14 Vite TSCE M5x14 Flathead screw M5x14 10
119 W2017/DDS Coperchio contralbero DDS/DDJ DDS/DDJ Balancer shaft cover 1
120 W300/A4 Cuscinetto banco 6205 c4 Insert crankcase 6205 c4 1
121 W10252 Tappo olio TCEM1M12x1.5 completo Complete oil plug TCEM1M12x1,5 1
122 W800 Raccordo depressione M8 esagonale Depression pipe fitting M8 hexagonal 1
123 W10267 Guarnizione rame 8x12x1 Copper gasket 8x12x1 10
124 V.TCE6X50 Vite brugola M6x50 Socket-head screw M6x50 10
125 V.TCE6X16 Vite brugola M6x16 Socket-head screw M6x16 10
126 W10277 Fascetta carburatore Carburettor clamp 1
127 V.TCE6X20 Vite brugola M6x20 Socket-head screw M6x20 10
127 W510/14 Vite brugola M6x14 8.8 Socket-head screw M6x14 8,8 10
128 W350/ACADEMY Convogliatore pacco lamellare DDJ academy Reed valve piramid conveyor academy 1
129 W740/MR Coperchio carter frizione Clutch guard cover 1
130 W351/RKF Guarnizione convogliatore pacco lamellare Conveyor reed valve pyramid gasket 1
131 W362/DVS Pacco lamellare DDS/DDJ/DVS con balestrini Reed pyram. DDS/DDJ/DVS with stiffener 1
132 W393/1KF30 Petalo carbonio spessore 0,30 Carbon petal thickness 0,30 1
132A W399/KF Balestrino carbonio 9/12 Carbon Flow deviat.9/12 1
133 W389 Piastrina lunga pacco maggiorato Enlarged pyramid long plate 1
134 W380 Viti fissaggio lamelle M3x5 Reeds fixing screws M3x5 10
135 W501/18 Vite TBCE M8x18 10.9 Roundhead screw M8x18 10.9 10
136 W2050/DDJ24 Collettore carburatore 24mm Inlet manifold 24mm 12
