Vortex V-V700 User Manual

Step 8
Assembly Instructions
a. Attach the Computer Holder Bracket (12) to the Handle Frame (2), fix using 2 x 6mm Flat Head
Philips Bolts (89).
b. Attach the Computer (29) to the Computer Holder Bracket (12), fix using 2 x 12mm Philips Bolts (88),
(Please note these two bolts were pre-fitted to the bottom of the Computer (29).
c. Connect Sensor wire (54) from the Main Body (1) to the Sensor wire from Computer (29).
11
