Vortex V-V700 - Component Identification; Parts Overview

Note: Some of the smaller components may be pre-fitted to larger components. Please check carefully
before contacting Argos regarding any missing components. Total mass of the product is 44kg. Total
surface area of equipment is 115 × 51cm.
Components - Parts
Please check you have all parts listing below
2
27. Saddle × 1
20. Pedal (Left/Right) × 1Set
29. Computer × 1
9. Front Stabilizer × 1
8. Rear Stabilizer × 1
1. Main Body × 1
2. Handle Frame × 1
3. Handle Support Frame × 1
4.&5. Saddle Post Assembly × 1
12. Computer Holder Bracket × 1
32. Water Bottle Rack × 1
6.&7. Elbow Pad Assembly(Left/Right) × 1Set
1. Main body × 1
2. Handle frame × 1
3. Handle support frame × 1
4&5. Saddle post assemble × 1
29. Computer × 1
32. Water bottle rack × 1
27. Saddle × 1
12. Computer holder bracket × 1
20. Pedal (Left/Right) × 1 set
9. Front stabilizer × 1
8. Rear stabilizer × 1
6&7. Elbow pad assembly (Left/Right) × 1 set
