Vortex V-V700 - Comprehensive Parts List

Part
Description
QTY
Part
Description
QTY
1
Main Body
1
29
Computer
1
2
Handle Frame
1
30
M6 Knob
2
3
Handle Support Frame
1
31
M8×14mm Knob
1
4
Saddle Adjustable Support
1
32
Water Bottle Rack
1
5
Saddle Support
1
33
Axle
1
6
Right Elbow Pad
1
34
Reed
1
7
Left Elbow Pad
1
35
Brake Sheet
1
8
Rear Stabilizer
1
36
Brake Bracket
1
9
Front Stabilizer
1
37
PL1350mm Belt
1
10
U-Shaped Locking Bracket
1
38
Belt Cover
1
11
M6
×
45
×Φ
12.3mm Tension Bolt / Zinc
2
39
Belt Rear Cover
1
12
Computer Holder Bracket
1
40
Front Fork Left Cover
1
13
Fly Wheel Inner Sleeve
1
41
Front Fork Right Cover
1
14
Brake
1
42
Brake Holder
1
15
Transport Wheel Inner Sleeve
2
43
Φ8mm Spring Washer
4
16
Fly Wheel
1
44
40×80mm Elliptical Sleeve
2
17
Belt Pulley
1
45
60×20×2mm Flat Elliptical End Cap
2
18
Drive Shaft Assembly
1
46
Elbow Pad Rubber Bushing
2
19
Crank (L/R）
1
47
Ø25×2mm Flat End Cap
2
20
Pedal(Left & Right)
1
48
Ø25×2mm Cone End Cap
4
21
Level Foot
4
49
80x40×1.5mm Flat Elliptical End
Cap
1
22
M6 Hex Nut
4
50
Right Base Stabilizer End Cap
2
23
Ø9.8×Ø1.2×70mm Spring
1
51
Left Base Stabilizer End Cap
2
24
Brake Knob
1
52
Transport Wheel
2
25
M16 Lock Knob
2
53
Brake Sticker
1
26
M10 Knob
1
54
Console Sensor Wire
1
27
Saddle
1
55
Ø10×2.0mm Magnetic
28
M10×20mm L-Shaped Lock Knob
1
56
U Shaped Seat Locking Bracket
1
Parts List
24
