Vortex V-V700 User Manual

Part
Description
QTY
Part
Description
QTY
57
M12 Level Foot Lock Nut
2
75
Φ8mm Washer
14
58
40×20×2mm Flat End Cap
2
76
M8 Aircraft Nut / Black
5
59
M5×5mm Dome Heat Philips Bolt
1
77
M6×16mm Philips Bolt/Black
2
60
Ø5mm Spring Washer/Black
5
78
Ø25×20.5×4/Zinc
1
61
Ø5mm Washer/Black
5
79
M20 Aircraft Nut
1
62
ST4.2×15mm Dome Head Philips
Screw
2
80
M6 Aircraft Nut/Zinc
2
63
M5×30mm Dome Head Philips
Bolt/Black
2
81
M6×40mm Allen Bolt/Zinc
2
64
M5 Aircraft Nut/Black
2
82
Ø6mm Washer/Zinc
2
65
M12 Cap Nut /Chromed
2
83
ST4.2×20mm Dome Head Philips
Screw/Black
2
66
Ø12mm Spring Washer/Chromed
2
84
ST4.2×15mm Dome Head Philips
Screw/Black
6
67
φ
20
×φ
12.5
×
5mm Washer/Zinc
2
85
M8×12mm Round Head Allen Bolt/Zinc
2
68
M12×1/5T Conical nut /Zinc
4
86
M10×1.25mm Flange Nut
2
69
Ø17×12.5×2mm Washer/Zinc
1
87
ST4.2×15mm Dome Head Philips
Screw
2
70
6301-2RZ Bearing
2
88
M5×12mm Philips Bolt
2
71
M5×15mm Flat Head Philips Bolt
4
89
M6×6mm Flat Head Philips Bolt
2
72
6004-2RS Bearing
2
90
φ18×φ6.5×R29×1.5mm Arc Washer
2
73
M8×12mm Round Head Allen
Bolt/Zinc
2
91
Square Nut
1
74
M8x20mm Allen Bolt
9
92
M6 Aircraft Nut/Zinc
3
Parts List
25
