PART NAMES AND FUNCTIONS
81. Booth Output jacks
This stereo pairs of unbalanced RCA jacks provide a unbalanced line level output with independent front panel
BOOTH LEVEL control
.
82. Channel Line/Phono Selector switches
These switches are used to change the voltage line levels of where respected LINE/PHONO RCA input jacks.
When connecting turntables with magnetic cartridges to these jacks be sure the corresponding switch is in the
“PHONO” position, and when using line level input devices be sure the switch is in the “LINE” position.
: Always be sure main power is shut off before change the position of the LINE LEVEL selector
switch.
83. GND (Ground Terminal)
Be sure to connect turntable ground leads to either or both of the two available GROUND terminals. This will
reduce the humming and popping noises associated with magnetic phono cartridges.
84. Input jacks
Turntables equipped with MM pickup cartridge (All DJ turntable use MM pickup cartridges) may be connected
to these jacks as long as the LINE/PHONE selector switches
is in the “PHONE” position. CD players, Tape
Decks and other line level instruments may only be connected to these jacks as long as the LINE/PHONE
selector switches
is in the “LINE” position. Input volume will be controlled by the INPUT GAIN CONTROL
knob
.
85. Microphone 2 jack
This combo jack will accept a standard 1/4 plug or XLR 3-pin balanced male plug. The volume output level for
microphone will be controlled by its own respective MIC 2 LEVEL CONTROL knob
.
86. Kensington lock
Standardized connection for theft protection.
