Voxoa S60 - Technical Specifications; General and Electrical Specifications; Audio Input;Output Performance

80
ENGLISH
SPECIFICATIONS
1. GENERAL SECTION
POWER :
AC100-240V, 50/60Hz, 21WATTS
DIMENSION :
420 (W) X 298.8 (D) X 89 (H) mm
WEIGHT :
4.42 kg
2. INPUT/OUTPUT IMPEDANCE & SENSITIVITY : (EQ FLAT, MAXIMUM GAIN, LOAD=100K OHM)
‧
INPUT IMPEDANCE AND REFERENCE INPUT LEVEL
LINE:
PHONO:
MIC:
‧
OUTPUT IMPEDANCE AND LEVEL
MASTER:
MASTER BAL(load=600 ohm):
BOOTH:
PHONES (load=32 ohm):
3. FREQUENCY RESPONSE: (EQ FLAT, MAXIMUM GAIN, LOAD=100K OHM
LINE:
PHONO:
MIC:
4. THD + N: (EQ FLAT, MAXIMUM GAIN, w/20kHz LPF, A-WEIGHTED, LOAD=100K OHM)
LINE:
PHONO:
MIC:
5. MAXIMUM INPUT: (1KHz, THD=1%, EQ FLAT, MAXIMUM GAIN, LOAD=100K OHM)
LINE:
PHONO:
MIC:
47K OHM /-14dBV (200mV) +/-0.1dB
47K OHM /-50dBV (3.16mV) +/-0.1dB
10K OHM /-50dBV (3.16mV) +/-0.1dB
1K OHM /0dBV (1V) +/-3dB
600 OHM /+4dBm (1.23V) +/-3dB (BETWEEN HOT AND COLD)
1K OHM /0dBV (1V) +/-3dB
33 OHM /0dBV (1V) +/-2dB
20 - 20K Hz +/-2dB
20 - 20K Hz +2/-3dB (RIAA)
20 - 20K Hz +2/-3dB
LESS THAN 0.06% @ 1 KHz
LESS THAN 0.08% @ 1 KHz
LESS THAN 0.15% @ 1 KHz
MORE THAN +0dBV
MORE THAN -36dBV
MORE THAN -36dBV
