MIDI MAP
(
HEX
)
FUNCTION Type
DECK A
FUNCTION
CODE (SHIFT)
LED
NOTE
DECK B
FUNCTION
CODE (SHIFT)
LED
NOTE
CENTER
DECK
FUNCTION
CODE (SHIFT)
LED
NOTE
ACTION
SW 16(55) 16(55) 7FH:ON 00H:OFF
SW 17(56) 17(56) 7FH:ON 00H:OFF
A.CUE
SCRATCH
SW/LED 18/18(57) C1 18/18(57) C1 7FH:ON 00H:OFF
VINYL SW/LED 19/19(58) C#1 19/19(58) C#1 7FH:ON 00H:OFF
CDJ SW/LED 1A/1A(59) D1 1A/1A(59) D1 7FH:ON 00H:OFF
TIME SW 1B(5A) 1B(5A) 7FH:ON 00H:OFF
SGL/CTN SW 1C(5B) 1C(5B) 7FH:ON 00H:OFF
SW/LED 1D/1D(5C) F1 1D/1D(5C) F1 7FH:ON 00H:OFF
JOG SW/ENC 27/18(66/57) 27/28(66/67) 7FH:ON 00H:OFF
CUE
SW 1E(5D) 1E(5D) 7FH:ON 00H:OFF
CUE SW/LED 1F/1F(5E) G1 1F/1F(5E) G1 7FH:ON 00H:OFF
SW/LED 20/20(5F) G#1 20/20(5F) G#1 7FH:ON 00H:OFF
TAP SW/LED 21/21(60) A1 21/21(60) A1 7FH:ON 00H:OFF
SW 22(61) 22(61) 7FH:ON 00H:OFF
SW 23(62) 23(62) 7FH:ON 00H:OFF
PITCH
SLIDER
VR/CENTER
PITCH
BEND/28(67)
PITCH
BEND/28(67)
7FH:ON 00H:OFF
GAIN VR 11(50) 21(60) VR:00~7F
HIGH
VR/SW/
CENTER/LED
12/24/29/24
(51/63/68)
C2
22/24/29/24
(61/63/68)
C2 VR:00~7F
MID
VR/SW/
CENTER/LED
13/25/2A/25
(52/64/69)
C#2
23/25/2A/25
(62/64/69)
C#2 VR:00~7F
LOW
VR/SW/
CENTER/LED
14/26/2B/26
(53/65/6A)
D2
24/26/2B/26
(63/65/6A)
D2 VR:00~7F
CHANNEL
FADER
VR 10(4F) 20(5F) VR:00~7F
U1 LED 17 B0 17 B0 7FH:ON 00H:OFF
U2 LED 1B D#1 1B D#1 7FH:ON 00H:OFF
