APS997Z
Security and Remote Start
Quick Installaon Guide
For Complete Installaon Guide and Technical Support
Please Visit
www.voxxuniversity.com
Or Call
1-800-225-6074
Feature Programming
Remote Programming
2020 Voxx Electronics. All Rights Reserved.REV. B
Tach Programming
1 Shock
2 Trunk / Hood
3 Door
1 Run�me Expired
2 Remote Shutdown
3 Brake On
4 Manual Mode
5 Hood Open
6 Low / No Tach
7 Tach Programming
8 High Tach
Alarm
When the alarm is triggered the system will provide feedback to the user. Upon disarm,
the system will beep 4x and ash the LED to indicate the Alarm Trigger Zone.
Chirp Delete
System ARM/DISARM chirps can be toggled ON or OFF without entering the Feature
Bank programming.
1. Turn the ignion key ON/OFF.
2. Press and release the valet buon three (3) mes.
The system will respond with one (1) chirp for ON and two (2) Chirps for OFF. This
feature will not aect alarm trigger or programming.
User Programmable LED
System LED nocaons can be turned ON or OFF without entering Feature Bank
programming.
1. Turn the ignion key ON/OFF, ON/OFF.
2. Press and hold valet buon for ve (5) seconds.
The LED will ash one (1) me for ON, two (2) mes for OFF. This feature will not aect
LED ash during programming.
Remote Start
If the remote start fails to start the vehicle, the system will ash the vehicle parking
lights to indicate the cause.
Nocaons
The installer must manually congure the Engine Conrmaon method in Feature Bank
3, Feature 5. The default method is “Tach”. When using the default “Tach” method, the
vehicle tach rate must be programmed. To enter tach rate programming:
1. Turn the ignion key ON.
2. Press and release the valet buon three (3) mes.
3. Turn the ignion key OFF.
4. Press and hold valet buon.
5. While holding valet buon, start the engine using the key.
6. Hold the valet buon for approximately ten (10) seconds. If connected to the vehicle
Tach source, the system will ash the parking lights one (1) me every second.
7. Release the valet buon. The system will turn on the parking lights for two (2)
seconds to indicate the tach rate is programmed.
The tach rate can also be programmed without the use of a valet buon. This is helpful
when using the OEM remote of CarLink system to control this module. To program the tach
rate without a valet buon:
1. Turn the ignion key to the ON posion and start the vehicle’s engine.
2. Wait for Engine RPM to lower to a normal idle.
3. Press and hold the vehicle’s brake pedal.
4. Press the LOCK buon on the OEM remote or the Carlink App.
Note: Programming tach signal via OEM or Telemacs control is only available on Firmware
v1.47 or Higher.
Data Protocol Selecon
The default data port protocol of this model is ADS (iDatalink 2-Way). This model is capable
of detecng the correct data port protocol (ADS or DBI) and automacally conguring
Feature Bank 2; Feature 18. To inialize the detecon procedure:
1. Press and hold the valet buon.
2. Cycle the vehicle’s Ignion ON/OFF two (2) mes.
3. Release the valet buon.
The system will automacally detect and set the correct data port protocol, ADS or DBI.
Note: This feature is only available on module rmware v2.0 or higher.
The APS997Z Feature Banks can be programmed by using the valet buon and remote. To
enter Feature Bank programming:
1. Turn the ignion key to ON.
2. Press and release the valet buon three (3) mes. System will beep and ash lights
one (1) me for Feature Bank 1, Remote Programming.
3. Cycle ignion key OFF/ON. System will beep and ash lights two (2) mes for
Feature Bank 2.
4. Press valet buon to cycle features. LED will ash to display feature number.
5. Press lock buon to cycle opons. System will beep to indicate opon number.
6. Cycle ignion key OFF/ON. System will beep and ash lights three (3) mes for
Feature Bank 3.
7. Press valet buon to cycle features. LED will ash to display feature number.
8. Press lock to cycle opons. System will beep to indicate opon Number.
The APS997Z Includes two (2) preprogrammed remotes. When adding addional remotes,
the remotes must be programmed to the system. Remote Programming is located in
Feature Bank 1. To enter Remote Auto Programming:
1. Turn the ignion key to ON.
2. Press and release the valet buon three (3) mes. System will beep and ash the
parking lights one (1) me.
Press the lock buon on each remote. The system will beep one (1) me to indicate the
remote has been programmed. Only primary remote funcons are auto programmed. This
Includes Lock, Unlock, and Trunk/Start.
If using AUX output control, you must manually program the AUX output channels to
the remote. Please see the complete installaon guide for manual remote programming
instrucon.
Note: If programming 2-Way remotes, wait for the remote to beep before programming
addional remotes. This beep is conrmaon that a 2-Way response has been received
from the main module.
Dome Delay Programming
This system can be programmed to ignore the vehicle’s theater dimming dome light. This
feature will be used when connecng the door trigger input to the dome light circuit for
alarm trigger.
Start with all doors closed and the vehicle dome light o.
1. Press Lock, Unlock, Lock, Unlock, Lock, Unlock, Lock. LED will light solid.
2. Open and close the driver door.
The system will monitor the dome light circuit. When the dome light turns o the system
will set the delay me and add an addional two (2) seconds.
Dome Delay Reset
1. Key ON/OFF, ON/OFF, ON/OFF.
2. Press and hold valet buon for ve (5) seconds.
The system will beep one (1) me to indicate reset is complete.
Programmable Input Control
Programmable Input Control allows any PIC be congured to one of the opons listed
below. This feature is accessible via FlashLogic Weblink or Weblink Mobile.
N.C. Door Trigger
External Start Ac�va�on
Pre-Warn Shock Trigger
Diesel Glow Plug
Door Trigger
Full Shock Trigger
Trunk Trigger
Parking Brake
Hood Trigger
Brake
10 Second Pulse
15 Second Pulse
20 Second Pulse
30 Second Pulse
Push & Hold
Latch ON/OFF
Latch 10min w/ RS
Latch Run�me
5 Second Pulse
1 Second Pulse
Headlight
Defrost
LED
Ch. 4 AUX
Ch. 5 AUX
Ch. 6 AUX
Ch. 7 AUX
Factory Disarm
Factory Arm
Accessory
Pulse During Crank
Pulse Aer Shutdown
Lock
Unlock
2nd Unlock
Trunk
Remote Start Status
Ignion
Ground While Armed
Ground While Disarmed
Domelight
Negave Output Control (NOC)
Negave output control allows any NOC to be programmed for any one of the opons
below. This feature is accessible via FlashLogic Weblink or Weblink Mobile.
AUX Output Control
Any AUX output can be congured using the AUX Control Menu. This feature is only
accessible via FlashLogic Weblink or Weblink Mobile.
1 Chirp 2 Chirp
3 Chirp 4 Chirp 5 Chirp 6 Chirp
1 Lock / Unlock Funcon 500ms 3.5sec
500ms L, DBL UL DBL L, 500ms UL DBL L, DBL UL 500ms L, 350ms UL
2 Ignion Lock OFF ON
3 Ignion Unlock OFF Unlock All Unlock Driver
4 Exterior Illuminaon OFF With Arm
With Disarm With Arm & Disarm
5 Auto Relock OFF Auto Lock Only Auto Lock & Arm
6 Auto Arming / Locking OFF Auto Arm Only
Auto Lock & Arm
7 Nocaon Sound Both Siren Horn
8 Horn Timing 16ms 30ms
40ms 50ms 10ms
9 Valet Override Method Valet Custom Code
Stand Alone Valet
10 Driver Priority Unlock OFF ON
11 Silent Choice OFF From Transmier
OEM Style
12 Security Prole All On Doors o Hood / trunk O All O All On w/ OEM RS
13 Door Trigger Input Negave Posive
14 Park Light / Trunk Swap OFF ON
15 Data Port Protocol ADS DBI
16 Dome Light Delay Timer OFF / Program 15sec
30sec 45sec 60sec 120sec
17 Alarm Trigger Legnth 30sec 45sec 60sec
90sec 120sec
1 Chirp 2 Chirp
3 Chirp 4 chirp 5 Chirp 6 Chirp
1 Defrost Output Pulsed 10min RS Runme
2 RS Start Nocaon ON OFF
3 RS Runme 15min 20min 45min 60min 5min 10min
4 RS Parking Lights Steady Flashing
5 Engine Conrmaon Tach Voltage
Data Hybrid
6 Voltage Level >0.5v B4 Start <0.5v B4 Start
7 Ignion 2 Output Ignion Accessory
Start
8 Ignion 3 Output Ignion Accessory Start
9 Accessory Output Accessory Ignion
Start
10 Transmission Auto Manual
11 Max Crank Time 0.8sec 1.0sec
1.5sec 2.0sec 3.0sec 4.0sec
12 Diesel Delay OFF Diesel 5 Diesel 10 Diesel 15 Diesel 20 Diesel 30
13 Temperature Start OFF 14F
5F 0F -4F -14F
14 Crank Duraon Averaging Preset
15 RS Shock Override Shunt unl Clear Shunt RS Cycle Shunt From TX
16 Turbo Timer OFF 3min
5min 10min
17 Start Acvaon Two Press One Press Three Press
18 RS Lock Funcon No Change UL Before L Aer
UL Before Start Lock Aer Start
19 Factory Disarm Output Single Pulse Double Pulse 350ms 500ms 800ms Same As Bank 2, F1
20 Addional Unlock Pulse No Pulse IGN, ACC, GWR
IGN,ACC,GWR,PASD
Features
Feature Bank 2
Opons
Features
Feature Bank 3
Opons
The Feature Banks below can also be programmed using the FlashLogic Weblink or Weblink Mobile.
