9
REAR OBSERVATION INSTALLATION
DISTANCE MARKER USE/INSTALLATION
- PLACE INDICATOR MARKERS (CONE, BOX
ANY REFERENCE OBJECT HANDY) BEHIND
VEHICLE AS IN FIGURE A.
- PLACE RANGE MARKER DECALS ON SCREEN
OF MONITOR OVER IMAGE OF INDICATOR
MARKERS ON GROUND BEHIND VEHICLE, AS
VIEWED ON THE MONITOR SCREEN.
- THIS GIVES YOU A VISUAL REFERENCE OF
ACTUAL DISTANCE BEHIND VEHICLE, AS
OBJECTS ARE VIEWED.
S
S
–
+
FIGURE B
FIGURE A
1FT
2FT
5FT
WIDTH OF VEHICLE
INDICATOR
MARKERS
