VTech A2210-NS User Manual

3
Installation option - converting from desktop to wall mount position
To mount the telephone base on the wall:
Set aside the handset. On the telephone base cradle, place a coin in the provided slit of the wall mount clip and rotate a half
turn (180 degrees). It locks into place with the protruding edge pointing towards the upper edge of the telephone base. This
protruding edge holds the handset when the phone is mounted on the wall.
Turn the telephone base over with the bottom side facing up. To remove the mounting bracket, rmly push both tabs downward
and pull up until both tabs release from the grooves.
Mount the telephone base on the wall by aligning the eyelets with the mounting studs of the wall plate. Then slide the telephone
base down on both mounting studs until it locks into place.
Replace the handset on the telephone base cradle.
1.
2.
3.
4.
Protruding edge
Mounting
bracket
Eyelets

VTech A2210-NS Specifications

Power

power requirement	Line powered 24V or 48V
message waiting signal	Steady/periodic high voltage pulse or periodic low voltage pulse

Memory

speed dial memory locations	up to 10
speed dial memory digits	up to 16

Weight and Dimensions

telephone base size	8.03 x 5.98 x 3.74 in (204 x 152 x 95 mm)
corded handset size	8.39 x 1.85 x 1.58 in (213 x 47 x 40 mm)
