VTech IS7121 User Manual

2
Battery
(1 for IS7121)
(2 for IS7121-2/
IS7121-22)
Battery compartment
cover
(1 for IS7121)
(2 for IS7121-2/IS7121-22)
Handset
(1 for IS7121)
(2 for IS7121-2/
IS7121-22)
Screws for doorbell
wall mount
(2 for IS7121/
IS7121-2)
(4 for IS7121-22)
Telephone base
Screw for
doorbell (bottom)
(1 for IS7121/
IS7121-2)
(2 for IS7121-22)
Telephone base
power adapter
Wall anchors
(2 for IS7121/
IS7121-2)
(4 for IS7121-22)
Telephone
line cord
Doorbell power
adapter
(1 for IS7121/
IS7121-2)
(2 for IS7121-22)
Handset charger
and charger adapter
(1 for IS7121-2/
IS7121-22)
Doorbell
(1 for IS7121/
IS7121-2)
(2 for IS7121-22)
Wall mount
bracket
Alkaline
batteries
(2 for IS7121/
IS7121-2)
(4 for IS7121-22)
Abridged user’s manual Installation guide
Abridged
user’s manual
Installation guide
Parts checklist
Your telephone package contains the following items. Save your sales receipt and
original packaging in the event warranty service is necessary.
Doorbell overview
/DOORBELL
Doorbell light
Infrared LEDs
Camera lens
Battery Pack / Bloc-piles : (2.4V Ni-MH) WARNING / AVERTISSEMENT : DO NOT BURN OR PUNCTURE BATTERIES. NE PAS INCINÉRER OU PERCER LES PILES. Made in China / Fabriqué en chine
THIS SIDE UP / CE CÔTÉ VERS LE HAUT
CR1232
Doorbell wall
mount cover
(1 for IS7121/
IS7121-2)
(2 for IS7121-22)

VTech IS7121 Specifications

Frequency and Channels

transmit frequency (handset)	1921.536-1928.448 MHz
transmit frequency (telephone base)	1921.536-1928.448 MHz
transmit frequency (doorbell)	1921.536-1928.448 MHz
channels	5

Display

LCD resolution	128 (RGB) x 160 DOTS
LCD size	1.77 inches
LCD type	TFT PANEL

Power Requirements

handset battery	2.4V Ni-MH battery
doorbell battery	Two 2A batteries
base unit power adapter input	100-120V AC 50/60Hz
base unit power adapter output	6V DC @ 400mA
doorbell unit power adapter input	100-240V AC 50/60Hz
doorbell unit power adapter output	6V DC @ 600mA
charger unit power adapter input	117V AC 50/60Hz
charger unit power adapter output	6V AC @ 300mA

Memory

directory memory locations	50
directory memory digits	up to 30 digits
directory memory characters	15 characters
caller ID log memory locations	50
caller ID log memory digits	up to 24 digits
caller ID log memory characters	15 characters
