Vtron C-DX503 - Page 36

User Manual Visionpro
®
C Series Display Cube
- -
29
Signal Loop-in/Loop-out Port
Signal Loop1-in Port
Connector Type
DisplayPort
Signal Format
SERDES
Dot Clock Frequency
27 MHz ~330MHz
Horizontal Frequency
31KHz~135KHz
Vertical Frequency
23Hz~121Hz
Resolution
640×480~4096×2160
Color Depth
24bit
Signal Loop1-out Port
Connector Type
DisplayPort
Signal Format
SERDES
Dot Clock Frequency
27 MHz ~330MHz
Horizontal Frequency
31KHz~135KHz
Vertical Frequency
23Hz~121Hz
Resolution
640×480~4096×2160
Color Depth
24bit
Signal Loop2-in Port
Connector Type
DisplayPort
Signal Format
TMDS
Dot Clock Frequency
27 MHz ~165MHz
Horizontal Frequency
31KHz~135KHz
Vertical Frequency
23Hz~121Hz
Resolution
640×480~1920×1200
Color Depth
24bit
Signal Loop2-out Port
Connector Type
DisplayPort
Signal Format
TMDS
Dot Clock Frequency
27 MHz ~165MHz
Horizontal Frequency
31KHz~135KHz
Vertical Frequency
23Hz~121Hz
Resolution
640×480~1920×1200
Color Depth
24bit
