User Manual Visionpro
®
C Series Display Cube
- -
15
⑦
Power output port of the VCL-3 interface box
Expansion port of the VCL-3A interface box
⑧
Power input port (low voltage) of VCL-3+ interface box
Power output port(low voltage) of VCL-3A interface box
2.2.2 Boards of VCL-3/VCL-3+ /VCL-3A Interface Box
 CP30SC Main Control Board（For VCL-3,VCL-3+ and VCL-3A interface
boxes）
CP30SC Main Control Board
7-SEG LED indicator
Desktop signal input port
Ethernet port
RS232 serial debug port
Sync signal input port
Sync signal output port
ON/OFF button
