Vtron C-DX503 - Page 23

User Manual Visionpro
®
C Series Display Cube
- -
16
 Specifications of CP30SC Main Control Board
DVI Output Port
Connector Type
DVI-D
Signal Format
TMDS
Dot Clock Frequency
25MHz-165MHz
Horizontal Frequency
35KHz-75KHz
Vertical Frequency
50Hz/60Hz
Resolution
640 × 480-1920×1200
Color Depth
24bit
Control Mode
I
2
C, SCL Frequency<100KHz
Input/ Output Ports of CP30SC Main Control Board
1）Desktop Signal Input Port
Digital
Connector Type
DVI-I
Signal Format
TMDS
Dot Clock Frequency
25-165MHz
Horizontal Frequency
31KHz-75KHz
Vertical Frequency
59Hz-61Hz
Resolution
640x480-1920x1200
Color Depth
24bit
Analog
Connector Type
DVI-I
Signal Format
RGBHV, RGsB
Dot Clock Frequency
25-165MHz
Horizontal Frequency
31KHz-75KHz
Vertical Frequency
59Hz-61Hz
Resolution
640×480～1920×1200
Color Depth
24bit
Sync Signal Amplitude
0.7Vpp~5.5Vpp
Sync Signal (green) Amplitude
-0.5Vpp~-0.3Vpp
RGB Signal Amplitude
0.5Vpp~1.0Vpp
2）Sync Signal Input/Output Port
Connector Type
BNC×2
Sync Signal Frequency
50～60HZ
Sync Signal Amplitude
3.0V~～3.6Vpp
