14
A. B.Insert a T-Joiner at the top of one side of each Lower
Frame Tube.
Ensure that they’re positioned at 45° angles, facing
outwards.
Slide both Lower Frame Tube pairs (with T-Joiners on
one side) into the bottom of the Upper Frame Tubes to
complete the climbing frame section.
Attach the completed Large Top Rails to the top of the Upper
Frame Tubes.
Note: If you have accessories, make sure to face the smaller
ends of the Top Rail to the side where you will attach those
accessories.
Important: Ensure that the T-Joiners are on the same
side as the Shade Cover Tubes.
10
STEP
CONTINUE TO STEP 15 FOR LARGE
T-Joiner must be on
the sides with the
Shade Tubes
9
STEP
MEDIUM:
