Vuly Quest - Page 17

17
A.
A. B.
B.
Insert a 4-way Joiner into the top of both Upper
Outer Tubes.
Insert an End Rail into either end of a Middle Rail. If you will attach Accessories:
Slide on the Accessory Joiners now, where you want to
position your accessories.
Connect a Long Outer Shade Tube through the
other end of one 3-way Joiner, and a Short Outer
Shade Tube through the other.
If you will not attach a Shade Cover: Connect Spacers here instead.
18
STEP
Insert the Short Side Rail into the 4-way Joiner with
the Long Outer Shade Tube, and insert the Long Side
Rail into the side with the Short Outer Shade Tube.
Connect the completed Middle Rail and End Rail set into the 4-way
Joiners on the Outer Tube sets from Step 17.
Note: Joiners must face downwards.
Note: Make sure all screws face
downwards.
Important: When repeating this Step for Extra Large,
swap the positioning of the Long Side Rail and Short
Side Rail.
Note: If you will attach Accessory Joiners to these
rails, connect them now.
LARGE AND EXTRA LARGE
17
STEP
LARGE AND EXTRA LARGE
19
STEP
LARGE AND EXTRA LARGE
20
STEP
