VWR Bead Mill MAX - Page 3

Touch Screen Control Panel
Loading Sample Tubes
For more details, please consult the full manual.
vwr.com
12° C
Bead Mill
6.00 m/s
Speed
03
Cycles
00:30 sec.
Dwell
01:00 min.
Timer
Start
2 mL
1. Program Menu
2. Program Name
3. Speed
4. Number of Cycles
5. Tube Setting
Touch Screen
Control and Display
6. Settings Menu
7. Timer
8. Dwell / Time Interval between Cycles
9. Processing Chamber Temperature
10. Start / Select / Pause Button
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Close the lid until the locking
handle clicks into place.
Move the locking switch to
the “LOCK” position.
A minimum of four tubes are
required and must be spaced
evenly*.
Screw down to secure tubes.
4.
6.
1.
3.
5.
Lock
Unlock
2.
*
*
CAUTION: DO NOT run without moving the switch to the
“Lock” position.
CAUTION: The unit will not run without the lid fully closed.
