VWR VWR-64B2 - Page 6

- 6 -
2) Check grounding spring to insure it is in the appropriate location. Make sure that the grounding
spring juts slightly out of the hole.
3) Install components following diagram below:
i. Bottom insert
ii. Centering ring [embossment side up]
iii. Weighing pan
Model: VWR-203B2, VWR-403B2, VWR-503B2
Components:
Installation:
1) Check that the grounding spring is in the correct location, the spring juts slightly out of the hole.
