www.prolight.co.uk TPX Series Power Ampliers User Manual

Operating instructions

Rack installation

TheTPXSeriesisbuiltfor19”racks.Therackyouuseshouldbea‘doubledoorrack’whereyoucan

openthefrontandrearpanel.Whenmountingtheamplierintotherack,pleasemakesurethatthere

isenoughspacearoundtheamplier.

Becarefulwhenmountingtheamplierintotherack.Puttheheaviestproductsintothelowerpart

oftherack.Beawarethatfasteningtheamplierwithfourscrewsonthefrontpanelisnotenough.

Iftheracksarebeingtransportedorusedformobileuse,additionallyfastentheproductsby

connectingtherearbracketswiththesideorgroundbarsoftherack.Inthisway,theamplier

cannotbepushedbackwards.Thefrontpanelisnotdesignedtoabsorbaccelerationforces

occuringduringtransportation.

Inputs

Shortcablesrunsimprovethesoundqualityremarkably.Inputcablesshouldbeshortanddirect,

sincehighfrequencieswillmostlybeabsorbedifthecablesareunnecessarilylong.Besidesthata

longercablemayleadtohummingandnoiseproblems.Ifthecablerunsareunavoidable,youshould

usebalancedcables.

Outputs

Thehighdampingfactorofyourampliersuppliesaclearsoundreproduction.

Unnecessarilylongandthincableswillinuencethedampingfactorandthusthelowfrequencies

inanegativeway.Inordertosafeguardgoodsoundquality,thedampingfactorshouldliearound50.

Thelongeracablehastobethethickeritshouldbe.

ConnectyourspeakersystemsviathelockingspeakerconnectorsortheBannana/Screwcombination

(red+,black-)

Connection to the mains

Connecttheamplieronlyafterhavingmadesurethatthecorrectvoltage(240V)issuppliedandthat

thegroundcableisearthed.ThisproductfallsunderClass1.Donotdetachthegroundcable.

W Audio TPX SERIES User Manual
