13F-054L
5
HANGING THE FAN 07
1. Align downrod and motor collar holes, re-insert
pins and screws.
2. Slip up canopy and canopy screw cover. Re-install hanger ball
with cross pin in correct place.
3. Install coupling cover, canopy screw ring, canopy and
downrod assembly into motor housing as shown.
To Next Page
