10 INSTALLING THE ADAPTER PLATE
14
1. Remove one of the three mounting plate screws from the
mounting ring and loosen the other two screws (do not remove).
2. Remove 1 of 3 screws and loosen the others (do not remove).
3. Install the adapter plate by twisting in the plate and tightening
the screws.
1. Twist and lock the adapter plate into place as shown.
2. Using the screw from the previous step, screw-in the
adapter plate.
