WAC ODYSSEY - Installing the Luminaire Module

19F-005L
17
1. Remove 1 of 3 screws from the adapter plate and loosen
the others.
2. Secure the luminaire module with the 3 screws to the
adapter plate.
16
INSTALLING THE LUMINAIRE MODULE 11
1. Attach LED wires from motor assembly to luminaire module.
