WAC ODYSSEY - Package Contents

9F-005L
NOTE: ** denotes nish code of fan
1
9
5
3
8
13
5
4
12
2
7
10
11
Canopy Ring
RPL-F005-CAN-**
Adapter Plate
Coupling
Cover
Safety Cable
6.5” x 19 x 2mm
Flat washer
(1pcs)
Safety Cable
10 x 76mm
Pan head
Philips wood
screw (1pc)
Safety Cable
3/16” (5.2 x 8.4 x
1.0mm) Spring
Washer (1pc)
Hardware Bag
RPL-F005-PARTS
Blade Screws
1/4” x 13mm
Slotted pan head
screws (10pcs)
LED Plate
8 x 1” Phillips Truss Head
Screws (4pcs)
Mounting Screw Bag
#10x38mm Pan Head
Phillip Screws (2)
Ø5*14*1mm Flat
Washer (2)
3/16” Star Washer (2)
Canopy
RPL-F005-CAN-**
Motor Housing
Fan Blade
RPL-F005-52-BD-**
Remote Control
RC20-WT
PACKAGE CONTENTS 04
Downrod
Assembly
Mounting
Bracket
RPL-F005-HGRASM-**
PC Shade
RPL-F005-GLA
Luminaire Module
F6IN-120V-R1-30
Receiver
F-R3-005-052
