4. Operation
4.1 Operation and Service Locations
See Graphic: wc_gr003183
Ref. Description Ref. Description
1 Engine oil dipstick 14 Engine oil filter
2 Fuel filter 15 Battery box
3 Manual fuel pump lever 16 Trailer hitch
4 Engine oil drain plug 17 Jack stand
5 Engine throttle solenoid 18 Rear stabilizers
6 Control panel 19 Drain cover
7 Ignition switch 20 Front impeller cover
8 Hour meter 21 Suction port
9 Bearing/Seal housing 22 Priming cover
10 Lifting point 23 Discharge port
11 Engine oil fill cap 24 Fuel fill cap
12 Inspection cover 25 License plate holder
13 Air cleaner 26 Circuit breaker
