PT 6 /... Maintenance
wc_tx000567gb.fm 47
5.25 Wiring Diagram Components
(0007174 > Rev 119; 0007175 > Rev 122)
Ref. Component Ref. Component
1 Cylinder head temperature
switch
14 Oil temperature sensor
2 Engine harness 15 Engine Control Unit (ECU)
3 Extension harness 16 Battery
4 Glow plug 17 Starter solenoid
5 Throttle solenoid 18 Voltage regulator
6 Hour meter 19 Low oil pressure switch - N.O.
7 Control panel 20 Low oil pressure switch - N.C.
8 Keyswitch 21 Diagnostic port
9 Glow plug relay 22 Cam RPM sensor
10 15A Fuse 23 Control solenoids
11 20A Circuit breaker 24 Engine alternator
12 Pump sensor 25 80A Fuse
13 Engine RPM sensor 26 Control panel harness
Wire Colors
B Black R Red Y Yellow Or Orange
G Green T Tan Br Brown Pr Purple
L Blue V Violet Cl Clear Sh Shield
P Pink W White Gr Gray LL Light blue
