OM 25-3503 us – Edition 4.1 * 2503_3503b610.fm 6-19
Technical datac
Legend
Authorized lift capacity applies to entire swiveling range of 360°.
All table indications in kg (lbs) and horizontal position on firm and level ground without
bucket or exchangeable attachment.
The machine’s lift capacity is restricted by the settings of the pressure limiting valves, the
hydraulic output and the hydraulic system’s stabilizing features.
Neither 75 % of the static tilt load nor 87 % of the hydraulic lift capacity is exceeded.
Calculation basis: according to ISO 10567.
Setting pressure on boom cylinder: 24,000 kPa (3,481 psi).
Lift capacities apply to machines under the following conditions:
• Lubricants and engine/machine fluids at the mandatory levels
• Full fuel tank
• Canopy/cabin
• Machine at operating temperature
• Operator weight 75 kg (165 lbs)
Designation Explanation
X Reach from live ring center
Z Load hook height in the respective range
max Authorized lift capacity with horizontal boom
L Stick short/long
