Introduction
Description
Do not touch hot surfaces, wait for parts to cool down.
Location
In the engine compartment.
Meaning
Do not loosen the securing screws before the extra weight has been secured.
Location
On the rear left and right of the upper carriage.
Description
The tank is hot and under pressure!
• Allow the fluids to cool down!
Carefully and slowly open the cover only after the radiator has cooled down, to allow
the pressure to escape.
Wear safety glasses and protective gloves when opening the cover.
Location
On the hydraulic oil reservoir.
Meaning
1. CAUTION, danger of being caught up!
2. Always use the handles to open and close the front window.
3. Always lock the front window with both locks!
Location
On the front window.
Meaning (option)
Always switch on the safe load indicator during lifting (gear) applications. Failure to
observe this can cause the machine to tip over, which in turn can cause serious injury and
even death.
Read and understand the Operator’s Manual.
Location
Canopy: on the right near the indicator
Cabin: on the window on the right
Up to serial no. AG04106:
Description
Read the Operator’s Manual before starting the machine.
Location
On the B pillar in the cabin.
Fig. 51: Hot surface
9705492
Fig. 52: Warning label
Fig. 53: Reservoir under pressure
Fig. 54: Front window
Fig. 55: Overload
Fig. 56: Read the Operator’s Manual
