Introduction
Description
1: Before performing maintenance or repairs on the machine, stop the engine, remove the
key, and read and understand the Operator’s Manual and the service manual.
2: Before leaving the machine lower all equipment to the ground, remove the key and lock
the controls.
Location
On the B pillar in the cabin.
Description
The coolant must have a thermal stability of at least Ã30 °C (Ã22 °F).
– see chapter 6.7 Coolant compound table on page 6-9
Location
In the engine compartment on the expansion tank.
Description
1: Operate only from the seat and fasten the seat belt to prevent falling out of the machine.
2: Operate within the stability limits of machine, do not overload, use only approved attach-
ments and operate only on solid ground. Follow the instructions in the Operator’s Manual.
Location
On the B pillar in the cabin.
Description (option 3503)
This label explains the functions of the slewing stabilizer blade.
Location
On the part on the right next to the stabilizer-blade lever.
Fig. 62: Read the manual before performing maintenance or
repairs
Fig. 64: Fastening the seat belt
Fig. 65: Operation of slewing stabilizer blade
