Wacker Neuson BFS 1345 User Manual

Technical data
TD00737en.fm 12
3. Technical data
BFS
1345 AB
BFS
1345 ABZ
BFS
1345 B
BFS
1345 BZ
Item no.
0008764
0610141
0610242
0008909
0610142
0610243
Length x Width x Height mm (in): 1,160 x 568 x 1,078 (45.67 x 22.36 x 42.44)
Weight kg (lb): 95 (209) 96 (212) 95 (209) 96 (212)
Powertrain From drive motor via belt to cutting blade
Max. cutting blade diameter mm (in): 450 (17.72)
Min. cutting blade diameter mm (in):
350 (13.78)
Max. cutting width mm (in): 12 (0.47)
Center bore mm (in): 25.4 (1.00)
Max. cutting depth cm (in):
17 (6.69)
Peripheral blade speed at
ø 350
ø 400
ø 450
(at rated engine speed)
m/s (ft/s):
m/s (ft/s):
m/s (ft/s):
40.3 (132)
46.1 (151)
51.8 (170)
Operating blade speed
(at rated engine speed)
rpm:
2,200
Water tank capacity l (gal):
32 (8.45)
Drive motor Air-cooled, single-cylinder, four-stroke gasoline engine
Engine displacement cm
3
(in
3
): 389 (23.73) 404 (24.65)
Rated speed rpm: 3,600
Rated power (*) kW/HP: 9.6/13 9.9/13.5
Fuel Normal gasoline, also unleaded
Fuel consumption
(at rated output)
l/h
(gal/h):
4.3
(1.14)
Fuel tank capacity l (gal): 6.5 (1.72) 7.0 (1.85)
Oil capacity l (gal): 1.1 (0.29) 1.2 (0.32)
Oil specification SAE 15W-40
Spark plug Type: NGK BPR6ES
(*) Corresponds to the installed effective power in accordance with Directive 2000/14/EC
Sound pressure level at
operator's station
L
PA
: 97 dB(A)
Weighted effective acceler-
ation value according to
EN ISO 5349
m/s
2
:
6.2 7.5

Wacker Neuson BFS 1345 Specifications

General

Brand	Wacker Neuson
Model	BFS 1345
Category	Saw
Language	English
